40′ LNG Tank Container

Product positioning and key values

The 40 ft LNG ISO cryogenic container is a robust, vacuum-insulated system for the transport, temporary storage and delivery of liquefied natural gas.

Primary purpose: transport, temporary storage and delivery of LNG
Typical configuration: 40 ft ISO cryogenic container for LNG (UN 1972)
Typical users: energy, industry, remote locations, microgrid projects, backup power, marine and rail logistics
Added value: integration with a regasification skid, telemetry and cloud monitoring

Core operating, service and production characteristics

Product type

40 ft ISO cryogenic LNG container

Medium

LNG / liquefied natural gas

Typical operating point

6 bar

Holding time

86 days at an operating pressure of 6 bar

Boil-off rate

0,19 kg/dan

Heat in-leak

1.12 W according to the operating calculation based on BOR

Total LNG mass

15,000 kg per container

Vacuum warranty

minimum 5 years for a vacuum of 0.003 mbar

Warranty period

18 months; for larger quantities, 24 months is also possible

Periodic service

every 5 years

Safety valves

in the EU, most commonly every 2 to 2.5 years

Production capacity

500 annually; with reinforcement 600–700

Why is CTT differentiated?

Two vacuum connections sealed with flanges for a reliable and sustainable vacuum.
SI powder vacuum insulation; no MLI and no perlite.
Higher resistance to compression fatigue and vacuum loads compared with lighter designs.
Suitable for more demanding climate and logistics conditions and a more robust transport regime.
High-inertia, heavy-duty and high-reliability product positioning.

Thermal and operational indicators

Long storage cycles and low thermal losses

LAn 86-day holding time enables safe transport, temporary storage and a longer logistics cycle without unnecessary product loss.

Filling
01
Transport
02
Temporary storage
03
Delivery
04
Holding time 86 days at 6 bar
Boil-off rate 0.19 kg/day very low daily loss
Heat in-leak ≈ 1.12 W estimate based on BOR

40 ft cryogenic platform at 6 bar

Breadth of competence: the platform also covers other cryogenic media

LNG / Methane
BOR kg/dan 0,19
Remark 15.000 kg
Nitrogen
BOR kg/dan 7,0
Remark 18.407 kg
Oxygen
BOR kg/dan 7,40
Remark 18.407 kg
Argon
BOR kg/dan 10,90
Remark 18.407 kg
Ethylene
BOR kg/dan 0,84
Remark 18.407 kg
Helium
BOR kg/dan 54
Remark 14.343 kg
Liquid Hydrogen
BOR kg/dan 0,35
Remark 2.467 kg
